Bio Diesel Installations

Bio Diesel

Bio Diesel comes from a wide selection of sources. Including recycled cooking oil, soybean oil and animal fats. The main source being from biological and plant material. The main selling point of bio fuels is the fact that they come from a renewable energy source. From an ecological point of view and the low carbon future to meet the 2050 carbon commitment.

HVO

Both FAME (Fatty Acid Methyl Esters) and HVO (Hydrotreated Vegetable Oil) are made from renewable feed stocks and thus can contribute to meeting renewable fuels blending targets and reducing well-to-wheels CO2 emissions. HVO does not contain oxygen and is chemically similar to molecules that are found in conventional diesel. Blends of HVO and diesel can meet BS EN 590 or BS 2869 Class A2. These specifications do not place a limit on the amount of HVO in a blend. The quality of HVO by itself is specified by BS EN 15940. HVO has similar storage and handling considerations compared to conventional diesel. FAME contains oxygen, which makes it different than the chemicals in conventional diesel. The standard diesel grades BS EN 590 and BS 2869 Class A2 allow up to 7% biodiesel and are labelled B7. FAME blending can present some challenges in diesel storage and handling. Depending on FAME quality, impurities present may contribute to filter blocking, particularly at lower temperatures. In addition, when B7 diesel is stored improperly or with excess water, FAME may promote micro biological growth.

Bio Diesel Pipework Installations

Fuel Storage Systems are the turnkey solution for bio fuel systems on CHP and power generation systems, We can complete the full package including: groundwork's, fuel storage tanks, gauging, pump sets, fuel management systems, pipework, trace heating, lagging and we operate on a nationwide platform providing installation and maintenance solutions.

Our vast range of above and below ground fuel fuel storage tanks complete with circulation and heat pumps provide solutions for every requirement with options from 1,000 right up to 150,000 litres.

Bio Fuel Equipment

Geberit Mapress

OmegaFlex DoubleTrac

Geberit Mapress

Stainless Steel 1.4401 (BS316) in accordance with DIN EN 10088.
Suitable for Petrol, Diesel, Gasoil, Bio Diesel up to B100, Ethanol, Kerosene and Adblue.
FKM blue seal is suitable for a maximum operating pressure of 16 Bar.
Press fit indicator.

Durapipe PLX

OmegaFlex DoubleTrac

Geberit Mapress

Material: HDPE100 with permutation barrier layer. Primary pipe pressure rating 10 bar.
Secondary pipe pressure rating 4 bar.
Suitable for Petrol, Diesel, Gasoil, Bio Diesel up to B100, Ethanol up to E85, Kerosene and Adblue.
Corrosion resistant.
UV stable suitable for above ground applications.
30-year design life. Approvals: EN14125 Standard Pipe.

OmegaFlex DoubleTrac

Trace Heating Thermostat

Primary pipe pressure rating 150 PSI.
Secondary pipe pressure rating 75 PSI.
Suitable for Petrol, Diesel, Gasoil, Bio Fuels, Kerosene and Adblue.
End connections available in brass, alloy or stainless.
Corrosion proof with PE-LD casing.
Salt water resistant ideal for marina installations.
UV stable.

Trace Heating Thermostat

Insulated Aluminium Pipework Lagging

Trace Heating Thermostat

They can be used for frost protection and process temperature maintaining of pipe work and storage tanks. Units may be used as an air sensing or pipe sensing thermostat. The unit is supplied in the air sensing mode with capillary bulb fixed to the enclosure. Removal of the bulb from the housing tube converts the unit to pipe sensing.

Type STCI has a transparent lid which allows the user to see the temperature set point without opening the unit. The unit is also fitted with indicating neons that show ‘MAINS ON’ and ‘HEAT ON’

Self Regulating Heat Trace Tape

Insulated Aluminium Pipework Lagging

Manufactured to: To BS EN 62395-1:2013
Quality assurance: BS EN ISO 9001 : 2008
Power ratings: 10 to 40 w/m @ 230V 10 & 20 w/m @ 110V
Temperature withstand: Dependant on Variant – Refer to Individual Product Data Sheet
Tape will not overheat, even if overlapped
Good Chemical Resistance
Simple terminations
Types FBT & H2OWAT Tapes can be used with Insulation Displacement Connectors (IDC) Fast Connection Systems

Insulated Aluminium Pipework Lagging

Grade: 1006, 1100, 3003, 3105, 5005
Temper: O, H12, H14, H16, H24, etc.
Common use: 3003 H14 H16, 1100 H14 H16, 5005 H14
Type: Coil roll Application: Industrial
insulation jacketing, cover, insulation protective jacketing
Thickness: 0.3-1.5mm
Width: 914mm, 1000mm, 1219mm
Length: 20, 25,30, 60, 90m per roll or as per clients
Surface Treatment: Plain, Flat, mill finish, Embossed Moisture barrier: polysurlyn, craft paper Certificate: ISO9001, GB/T3880, ASTM B209
